    Fully Automatic 3 Layer Carton Box Production Line / Cardboard Production Line

    Ask Lasest Price
    Brand Name : ZHAOLI
    Model Number : WJ
    Certification : CE
    Price : Negotiable
    Payment Terms : L/C, D/A, D/P, Western Union, T/T
    Supply Ability : 20 line per month
    Delivery Time : 90-120 daye after receive deposit
    • Product Details
    • Company Profile

    Fully Automatic 3 Layer Carton Box Production Line / Cardboard Production Line

    Fully Automatic 3 Layer Carton Box Corrugated Cardboard Machine Production Line


    ※ main technical parameters and requirements in production line type:

    WJ100-1800-I type three layer corrugated paperboard production line:

    The maximum production width of the corrugated cardboard:1800mm

    Design speed:100m/min

    Economic speed:60-80m/min

    note:Production line speed test paper should meet the following requirements:(the surface temperature of the equipment is not less than 172℃)

    ﹡ Paper rating of not less than B grade ﹡Paper moisture content of about:11%±2%

    ﹡ top paper:100—250g/m2 ﹡core paper:100--250g/m2

    ﹡ corrugated paper:100—200g/m2

    1. Flute-type combination:A ,C, B, E(as customers’ requirement)

    2. Steam the necessary requirements:

    3. amount of steam 2500—3000Kg/Hr ﹡the highest pressure:1.2Mpa

    4. common pressure:0.8-1.1Mpa

    5. power supply:380V 50Hz Three-phase four-wire system

    6. equipment installed total power:about120KW

    7. The actual power consumption:about 60KW(full speed)

    8. equipment covers:about40m×10m×5m(Specific length of foundation Figure prevail)

    9. Equipment out of paper orientation:According to the user to determine the transmission plant set left or right position

    10. Equipment applicability,Available in A, B, C class domestic or imported paper Paper


    package:

    The normal package is plastic film(Size: L*W*H). If export to european countries,the wooden box will be fumigated. If container is too tigher,we will use pe film for packing or pack it according to customers special request.


    Our team:
    Our company has the purchasing department, production department, technical department, inspection department, sales department etc, perfect management mechanism, to improve the working efficiency and product quality.


    Our service:
    Our company provides technical support and after-sales service to ensure that our customers have a better purchase and use experience. We are committed to the following:

    1. We guarantee one year for whole machine (except the easy-wear parts) , and provide the technic support for the whole
    life of the machine .

    2. We provide online service if customer has any problems , and will provide pictures or video for easy understanding if
    necessary in whole life time of machine.

    3. If customer need , we will dispatch our engineer (get paid) overseas for installation , debugging and training .

    4. If any unsatisfactory, please email us or call us at any time
